VALLOX 90 SE/MC/MV FILTER SET (245X212X48)

Filter set suitable for Vallox 90 SE/MC/MV (245X212X48) heat exchanger. The filter set is designed for filtering supply and exhaust air.

Vallox 90 SE/MC/MV – user benefits

The Vallox 90 SE/MC/MV filter set is designed to ensure stable and effective air filtration during daily use. This helps maintain good indoor air quality and reliable operation of the heat recovery unit.

• - reduces the amount of dust and particulate matter in the supplied air,
• - improves the indoor microclimate,
• - more effective protection against pollen using the F7 filter,
• - protects the heat exchanger and fans from contamination,
• - maintains stable air flow and quiet operation of the device.

Filter options – Efficient

The efficient set (G4 + G4 + F7) consists of three filters. An additional F7 filter is installed on the supply air side and ensures a higher level of supply air purification. This option is recommended for allergy sufferers and those living in areas with higher air pollution.

Differences between F7 and G4 filters

The G4 filter is used for filtering supply and exhaust air. It traps medium-sized particles and provides protection against solid particles with a size of about 10 μm.

The F7 filter is used only for filtering the supply air. It traps extremely fine particles and effectively protects against solid particles with a size of about 0.3 μm.

Compatibility

The filters are suitable for the following Vallox heat recovery unit models:

• - Vallox 90 SE
• - Vallox 90 MC
• - Vallox 90 MV

VALLOX 90 SE/MC/MV filter set specification

Filter dimensions:

G4 filters: 320X200 mm and 315X265 mm
F7 filter: 245X212X48 mm

Technical characteristics:

• - made in Lithuania,
• - moisture-resistant cardboard frame,
• - large filtration area,
• - ECO green solution,
• - long service life.

Compliance with standards:

• - VDI 6022 – ventilation hygiene standard,
• - DIN 53438 – flammability classification,
• - ISO 16890 – air filter quality standard,
• - EN 779:2012 – filtration classification (G4 / F7).

ECO green

Filtrai1.lt filters feature "ECO green" features. They are made from recycled and durable materials, maintaining high filtration efficiency and durability.

Hygiene standard VDI 6022

The filters sold by Filtrai1.lt comply with the VDI 6022 ventilation hygiene standard. This means that the filter materials used do not create conditions for the growth of bacteria.

Flammability DIN 53438 classification

Filters sold at Filtrai1.lt are tested and meet the requirements of DIN 53438 flammability classification.

DEEP PLEAT technology

The filters are manufactured using DEEP PLEAT technology. The pleated filter material maintains a regular V-shape, allowing for maximum use of the filtration area and extending the filter's service life.

Recommended replacement frequency:

It is recommended to change the heat exchanger filters at least 2-3 times a year, and more often if the contamination is greater.

Discount:
Buy 10 sets or more and contact us for a better price.
