VALLOX 110 MV/SE / ValloPlus 350 FILTER SET (248X230X96) (No. 22/24)

Filter set suitable for Vallox 110 MV/SE / ValloPlus 350 (248X230X96) heat exchanger. The filter set is designed for filtering supply and exhaust air.

Vallox 110 MV/SE / ValloPlus 350 – user benefits

The Vallox 110 MV/SE / ValloPlus 350 filter set is designed to ensure stable and effective air filtration during daily use. This allows you to maintain good indoor air quality and reliable operation of the heat recovery unit.

• - reduces the amount of dust and particulate matter in the supplied air,
• - improves the indoor microclimate,
• - more effective protection against pollen using the F7 filter,
• - protects the heat exchanger and fans from contamination,
• - stable air flow and quiet operation of the device are maintained.

Filter options – Efficient set

The efficient set (G4 + G4 + F7) consists of three filters. An additional F7 filter is installed on the supply air side and ensures a higher level of supply air purification. This option is recommended for allergy sufferers and those living in areas with higher pollution.

Differences between F7 and G4 filters

The G4 filter is used for filtering supply and exhaust air. It traps medium-sized particles and provides protection against solid particles with a size of about 10 μm.

The F7 filter is used only for filtering the supply air. It traps extremely fine particles and effectively protects against solid particles with a size of about 0.3 μm.

Composition and compatibility

The filters are suitable for the following Vallox heat recovery unit models:

• - Vallox 110 MV
• - Vallox 110 SE
• - ValloPlus 350 MV
• - ValloPlus 350 SE
• - ValloPlus 350 SC
• - filter set No. 22/24

VALLOX 110 MV/SE / ValloPlus 350 filter set specification

Filter dimensions:

G4 filters: 246X228 mm and 400X253 mm
F7 filter: 248X230X96 mm

Technical characteristics:

• - made in Lithuania,
• - moisture-resistant cardboard frame,
• - large filtration area,
• - ECO green solution,
• - long service life.

Compliance with standards:

• - VDI 6022 – ventilation hygiene standard,
• - DIN 53438 – flammability classification,
• - ISO 16890 – air filter quality standard,
• - EN 779:2012 – filtration classification (G4 / F7).

ECO green

Filtrai1.lt filters feature "ECO green" features. They are made from recycled and durable materials, while maintaining high filtration efficiency.

Hygiene standard VDI 6022

The filter materials used comply with the hygiene requirements of VDI 6022 and do not create conditions for the growth of bacteria in the ventilation system.

DEEP PLEAT technology

The filters are manufactured using DEEP PLEAT technology. The pleated filter material maintains a regular V-shape, allowing for maximum use of the filtration area and extending the filter's service life.

Recommended replacement frequency:

It is recommended to change the heat exchanger filters at least 2-3 times a year, and more often if the contamination is greater.

Discount:
Buy 10 sets or more and contact us for a better price.
